gitlab-board

Extended kanban board application for GitLab Community Edition. It provides kanban board by assignee, grouped by teams.

Requirements

The application requires three scoped labels:

Status::{name} - status labels
Priority::{name} - priority labels
Type::{name} - task type

Installation

1. Configure environments

Copy .env.example and name it .env. Most environment variables are already set, but some still need to be filled in.

SECRET_KEY=[generate your own]
JWT_SECRET=[generate your own]
VITE_GITLAB_API_URL=[gitlab api url]
VITE_GITLAB_API_TOKEN=[gitlab api token]

Warning

Database password is set by default. Replace values in environments DATABASE_PASSWORD and POSTGRES_PASSWORD with a more complex one for security reasons.

2. Build images

Run next command

docker-compose build

Note

You will need to push images for production usage.

3. Configure Nginx

Nginx is used as reverse proxy. Copy nginx/board.conf to /etc/nginx/conf.d.

Board will be available at http://localhost:8000.

Warning

HTTPS is disabled by default. Enable it for production. Such as Let’s encrypt.

4. Deploying via docker-compose

Run next command

docker-compose up -d

Advanced

Customization

Custom Logo

The default logo can be changed. Add an VITE_LOGO_URL environment variable with image path.

Configuration

Frontend environment variables

VITE_BOARD_API_URL

Required

GitLab Board API URL.

VITE_GITLAB_API_URL

Required

GitLab API URL.

VITE_GITLAB_API_TOKEN

Required

GitLab API Token.

VITE_LOGO_URL

Optional

Logo URL. If not specified, the default logo is taken.

API environment variables

DEPLOYMENT_ENVIRONMENT

Required

Deployment environment. Can be PROD or LOCAL.

By default PROD.

SECRET_KEY

Required

A secret key for a particular Django installation. This is used to provide cryptographic signing, and should be set to a unique, unpredictable value.

See https://docs.djangoproject.com/en/4.1/ref/settings/#secret-key.

JWT_SECRET

Required

This is the secret key used to sign the JWT. Make sure this is safe and not shared or public.

CSRF_TRUSTED_ORIGINS

Required

A list of trusted origins for unsafe requests (e.g. POST).

See https://docs.djangoproject.com/en/4.1/ref/settings/#csrf-trusted-origins.

CORS_ALLOWED_ORIGINS

Required

A list of origins that are authorized to make cross-site HTTP requests.

DATABASE_HOST

Required

Database host.

DATABASE_PORT

Required

Database port.

DATABASE_NAME

Required

Database name.

DATABASE_USER

Required

Database user.

DATABASE_PASSWORD

Required

Database password.

TIME_ZONE

Required

Time zone database name. (e.g Europe/Berlin).

LANGUAGE_CODE

Optional

ISO 639-1 standard language codes (e.g ja). By default en-us.
